Rigid-flex-combined-pcb

Rigid-flex PCB integrates FR4 rigid soldering zones and PI flexible bendable sections into one single circuit board, eliminating extra connectors, saving internal assembly space and greatly improving vibration resistance and long-term folding durability for precision miniaturized equipment.

Inquiry

Rigid-Flex PCB is a composite circuit board laminated by rigid FR4 substrate and flexible PI polyimide FPC material. The rigid section is for SMT component soldering, while the flexible part can be bent, folded and twisted freely. It eliminates external connectors and loose cables, reduces product overall size, enhances shock resistance and bending fatigue resistance. We customize 4-layer to 8-layer stacked rigid-flex boards with ENIG, OSP, impedance control, halogen-free, automotive and medical compliance, applied in robotic equipment, endoscopes, foldable electronics, automotive ECUs, 5G RF modules and portable testing devices.

Product Parameters
PCB description
Model Number Rigid-Flex PCB
Place of Origin Shenzhen, China
Base Material FR4+Polyimide
Layers 4 L
Copper Thickness 1oz
Board Thickness 1.6mm
Min. Hole Size 0.15mm
Min. Line Width 3 Mil
Min. Line Spacing 0.1um(3 Mil)
Surface Finishing ENIG
Color Green Solder mask and no silkscreen
